Fiber Laser Marking
PL5-Pro
PL5-Pro
PL5-Pro
PL5-Pro

MAIN ADVANTAGES

  • One-key operation marking mode, simple and time-saving
  • Professional dust-proof & heat-dissipation design, effectively extending machine service life
  • Quick import of required marking graphics, supporting mobile phone reverse charging
  • Adopt Raycus special laser, stable light output, ensuring high-quality marking in harsh environments
  • One-piece steel construction, durable and resistant to external forces

SPECIFICATIONS

Product model PL5-PRO
The whole machine material Industrial-grade aluminum
Lasers Raycus Fiber Laser
Laser wavelength 1064NM
Actual output power ≥20W(standard) / ≥30W (optional)
Marking speed ≤1200NM/S
Main Controller 8 inch touch controller
Cooling System Air cooling at room temperature
Focus Lens 165MM focal length
Minimum line width 0.05MM
Repeat positioning accuracy 0.003MM
Marking range 80MM×80MM (standard) / 130MM×80MM (customizable)
Positioning method Red light indicator
